Modular NTP Server

Product Overview

The TS3000 is a modular NTP server designed to meet the unified timing requirements of network devices. By tracking Beidou, GPS, and NTP, it provides time synchronization for network cameras and other subsystems requiring timing, meeting the time synchronization needs of various industries.

Features:

High synchronization accuracy, easy operation, and reliable performance

Modular design allows for flexible module deployment to meet the needs of various industries

Modular plug-in design facilitates functional integration to meet diverse needs

Each time signal can have its own output format configured

Main Applications:

Network time synchronization applications of various sizes for users in industries such as enterprise, education, government, postal services, railways, and finance.

Technical Indicators

Project		Technical Specifications
GNSS	Warm Start Time	<1min
	Cold Start Time	<25min
1PPS Accuracy		≤100ns
NTP Accuracy		≤5us
Optical B-code accuracy		≤100ns
Timekeeping accuracy	Rubidium clock	≤3ms (365 days)
	Crystal clock	≤28us (24 hours)
NTP timing capability		10,000 times/second
Management Port		RS232, RJ45
Network Management Protocol		CLI, TL1, SNMP
Power Supply		90~240AC
Power Consumption		50W
Working Environment	Temperature	Crystal Clock (-10°C to +60°C) Rubidium Clock (-10°C to +45°C)
	Humidity	10% to 90%, non-condensing
Dimensions		483mm300mm44mm
Weight		≤5kg
